Dostava besplatna Spojke i zamašnjaci Xtreme KGM18631-3E Xtreme Performance 184mm Rigid Ceramic Triplate Plate Clutch Kit Incl Flywheel & CSC | race-shop.hr Prikaži uvećano

*38 838

Xtreme clutch

KGM18631-3E Xtreme Performance 184mm Rigid Ceramic Triplate Plate Clutch Kit Incl Flywheel & CSC

Xtreme Clutch delivers expertly engineered, high-performance clutch solutions for the street and track. Trusted by professional race teams worldwide, we provide the ultimate upgrade for your driving experience.

Novi proizvod

Privremeno nedostupno

3.006,60 € s PDV-om

Nažalost, proizvod je privremeno nedostupan. Molimo odaberite drugi.

Upit o proizvodu

Upit o proizvodu

KGM18631-3E Xtreme Performance 184mm Rigid Ceramic Triplate Plate Clutch Kit Incl Flywheel & CSC

KGM18631-3E Xtreme Performance 184mm Rigid Ceramic Triplate Plate Clutch Kit Incl Flywheel & CSC

Xtreme Clutch delivers expertly engineered, high-performance clutch solutions for the street and track. Trusted by professional race teams worldwide, we provide the ultimate upgrade for your driving experience.

Pošaljite pitanje ovoj trgovini.

* Obavezna polja

  ili  Otkaži

Upozoriti kad bude dostupno

Obavjestiti kad bude na lageru

KGM18631-3E Xtreme Performance 184mm Rigid Ceramic Triplate Plate Clutch Kit Incl Flywheel & CSC

KGM18631-3E Xtreme Performance 184mm Rigid Ceramic Triplate Plate Clutch Kit Incl Flywheel & CSC

Ako želite biti obaviješteni o dostupnosti proizvoda putem emaila, ispunite obrazac.

* obavezni podaci

  ili  Otkazati

Za automatsko obavještavanje o dostupnosti proizvoda,
klik na "Obavijesti nakon dostupnosti proizvoda".

KGM18631-3E

9337467166446

Xtreme Clutch delivers expertly engineered, high-performance clutch solutions for the street and track. Trusted by professional race teams worldwide, we provide the ultimate upgrade for your driving experience.

-3E

The Xtreme 184mm Race Clutch is an economically priced solution for those wanting a strong Race clutch without having to compromise on quality. The Race Clutch is a lightweight design for when every second counts.

 Ø184mm Light Diaphragm (2.6mm)Ø184mm Heavy Diaphragm (2.8mm)
Clamping Force950kg1080kg
Torque Rating1600Nm1820Nm
Bearing Contact Diameter44-52mm44-52mm
Bearing Load (@ 48mm)210kg260kg
Release Travel Required5mm5mm
Assembly Mass (without flywheel)4.75kg4.75kg
Disc Set Static Mass1.2kg
Friction Thickness New2.6mm (0.103")2.6mm (0.103")
Friction Thickness Worn2.36mm (0.093")2.36mm (0.093")

Product Features:

  • Push type billet alloy cover
  • 4140 Chromoly pressure plate
  • Hardened steel wear posts
  • High and low ratio pressure plate options
  • Low inertia
  • Serviceable components
  • SFI certified design

Tech. Info:

Reference: KGM18631-3E

Weight: 19.26

Note:

Clutch Disc Diameter (mm): 184
Clutch Disc Spline Count: 26
Clutch Disc Spline Diameter (mm): 28.6
Torque (Nm): 1830
Flywheel Step: +2.5mm
Design: Triple Plate
Stage: Multiplate - track use only
Clamp Load: 900Kg
Recommended for: Motorsport
Ring Gear Tooth count:
Additional information:

184mm Triple Plate

Suitable for:

- Holden/H Series/VE | 6.0i V8/2006.07-2013.05/L76, L77(364CUV8) 5967 Petrol 260 kW 354 BHP (2006.07 - 2013.05)
Holden/H Series/VE | 6.0 Flex/2010.09-2013.04/L77(364CUV8) 5967 Petrol 260 kW 354 BHP (2010.09 - 2013.04)
Holden/H Series/VE | 6.0i V8/2006.07-2013.05/L77(364CUV8), L98(364CUV8) 5967 Petrol 270 kW 367 BHP (2006.07 - 2013.05)
Holden/H Series/VE | 6.0i V8/2006.08-2013.05/L77(364CUV8), L98(364CUV8) 5967 Petrol 270 kW 367 BHP (2006.08 - 2013.05)
HSV/Senator/VE | 6.0i V8/2006.08-2013.04/LS2(364CUV8) 5965 Petrol 297 kW 404 BHP (2006.08 - 2013.04)
HSV/GTS/VE | 6.0i V8/2006.08-2008.03/LS2(364CUV8) 5965 Petrol 307 kW 418 BHP (2006.08 - 2008.03)
HSV/Senator/VE | 6.0i V8/2006.08-2008.03/LS2(364CUV8) 5965 Petrol 307 kW 418 BHP (2006.08 - 2008.03)
HSV/Clubsport/VE | 6.0i V8/2006.08-2008.06/LS2(364CUV8) 5965 Petrol 307 kW 418 BHP (2006.08 - 2008.06)
HSV/Maloo/VE | 6.0i V8/2007.10-2008.03/LS2(364CUV8) 5965 Petrol 307 kW 418 BHP (2007.10 - 2008.03)
HSV/GTS/VE | 6.2i V8/2008.04-2010.10/LS3(376CUV8) 6162 Petrol 317 kW 431 BHP (2008.04 - 2010.10)
Vauxhall/VXR8 Maloo/6.2/2008.04-2011.08/LS3(376CUV8) 6162 Petrol 317 kW 431 BHP (2008.04 - 2011.08)
HSV/Clubsport/VE | 6.2i V8/2008.04-2013.05/LS3(376CUV8) 6162 Petrol 317 kW 431 BHP (2008.04 - 2013.05)
HSV/Maloo/VE | 6.2i V8/2008.04-2013.05/LS3(376CUV8) 6162 Petrol 317 kW 431 BHP (2008.04 - 2013.05)
HSV/Senator/VE | 6.2i V8/2008.04-2013.05/LS3(376CUV8) 6162 Petrol 317 kW 431 BHP (2008.04 - 2013.05)
HSV/GTS/VE | 6.2i V8/2010.10-2013.05/LS3(376CUV8) 6162 Petrol 325 kW 442 BHP (2010.10 - 2013.05)
HSV/W427/VE | 7.0i V8/2008.07-2013.05/LS7 7009 Petrol 375 kW 510 BHP (2008.07 - 2013.05) ,

Ostavi komentar

Ostavi komentar







  ili  Poništi

Nema odgovora?
Postavite pitanje
Imate pitanje? Pronađite odgovor u raspravi.




MarkaModelTipKod motora
HSVClubsportVE 6.0i V8LS2(364CUV8) 5965 Petrol 307 kW 418 BHP (2006.08 - 2008.06)
HSVClubsportVE 6.2i V8LS3(376CUV8) 6162 Petrol 317 kW 431 BHP (2008.04 - 2013.05)
HSVGTSVE 6.0i V8LS2(364CUV8) 5965 Petrol 307 kW 418 BHP (2006.08 - 2008.03)
HSVGTSVE 6.2i V8LS3(376CUV8) 6162 Petrol 317 kW 431 BHP (2008.04 - 2010.10)
HSVGTSVE 6.2i V8LS3(376CUV8) 6162 Petrol 325 kW 442 BHP (2010.10 - 2013.05)
HSVMalooVE 6.0i V8LS2(364CUV8) 5965 Petrol 307 kW 418 BHP (2007.10 - 2008.03)
HSVMalooVE 6.2i V8LS3(376CUV8) 6162 Petrol 317 kW 431 BHP (2008.04 - 2013.05)
HSVSenatorVE 6.0i V8LS2(364CUV8) 5965 Petrol 297 kW 404 BHP (2006.08 - 2013.04)
HSVSenatorVE 6.0i V8LS2(364CUV8) 5965 Petrol 307 kW 418 BHP (2006.08 - 2008.03)
HSVSenatorVE 6.2i V8LS3(376CUV8) 6162 Petrol 317 kW 431 BHP (2008.04 - 2013.05)
HSVW427VE 7.0i V8LS7 7009 Petrol 375 kW 510 BHP (2008.07 - 2013.05)
HoldenH SeriesVE 6.0 FlexL77(364CUV8) 5967 Petrol 260 kW 354 BHP (2010.09 - 2013.04)
HoldenH SeriesVE 6.0i V8L76, L77(364CUV8) 5967 Petrol 260 kW 354 BHP (2006.07 - 2013.05)
HoldenH SeriesVE 6.0i V8L77(364CUV8), L98(364CUV8) 5967 Petrol 270 kW 367 BHP (2006.07 - 2013.05)
HoldenH SeriesVE 6.0i V8L77(364CUV8), L98(364CUV8) 5967 Petrol 270 kW 367 BHP (2006.08 - 2013.05)
VauxhallVXR8 Maloo6.2LS3(376CUV8) 6162 Petrol 317 kW 431 BHP (2008.04 - 2011.08)

Odgovara ovim vozilima
